Airgas Model L244DLB Brass Specialty High Purity Two Stage Mini Regulator With CGA x 1/8" FNPT Connection

Product Description

These compact, two-stage analytical series and high-purity stainless steel regulators are ideally suited for lecture bottles and other small cylinders. They are equipped with a CGA-180 connection for easy attachment to Airgas® lecture bottles. Other CGA-connections are available upon request, as the regulator is rated for 3,000 psig inlet pressure. This regulator also features a non-lubricated needle valve, designed to regulate outlet flow. Choose a brass model for analytical or non-corrosive service or a stainless steel model for mildly corrosive service. If used in corrosive service, a cross-purge assembly must be used.

Features

• Compact Design: Ideal for lecture bottles and small cylinders. Sensitive Diaphragm: Provides accurate pressure settings. 1 1/2" Gauges: Permit easy reading. Large Adjusting Knob: Provides excellent sensitivity over a wide range of settings. Needle Valve: Provides easy control of flow volume.

Specifications

Maximum Inlet Pressure: 3,000 psig Outlet Pressure Range: 0 - 100 psig Capacity (scfh @ Max Del. Pressure): 1,050 Relief Valve Setting: 210 Inlet Gauge Range: 0 - 3,000 psig Delivery Gauge Range: 0 - 100 psig Flow Capacity: Cv= 0.08 Ambient Operating Temperature: -40° F to +165° F Designed Leak Rate: Bubble-Tight (helium) Weight: 1.5 lbs Ports: 1/8" FNPT Decay Inlet Characteristic: 0.58/100 psi

• Stage: Two Stage
• Brand: Airgas
• Material: Brass
