Airgas Model N140FHF Brass Specialty High Purity High Flow Pressure Regulator With 1/2" FNPT Connection

Name: Airgas Model N140FHF Brass Specialty High Purity High Flow Pressure Regulator With 1/2" FNPT Connection
Brand: ItsMyLe
Price: 807.0 USD
Availability: InStock

$807.00 USD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

This series of regulators is used for applications requiring high gas flow rates and a compact design. These regulators can handle flows up to 250 liters per minute of nitrogen with only a 5 psig pressure drop. In addition, these units will handle hydrogen flow up to 1,000 liters per minute without the resonance problems associated with other regulators in this same application.

View full details

Model

» N140FHF

Usage

» Specialty High Purity

Material

» Brass

Regulator Type

» High Flow Regulator

Inlet Connection

» 1/2" FNPT

Outlet Connection

» 1/2" FNPT

Max Outlet Pressure

» 250 psig

Gauge Diameter

» 2 1/2"

Features
Stainless Steel Diaphragm: Provides precise pressure control and superior leak integrity. Cv Flow Coefficient = 1.0 to permit high flows with minimum pressure drop. Stabilizer Springs: Eliminate regulator resonance.
Specifications
Maximum Inlet Pressure: 3,000 psig Outlet Pressure Range: 0 - 250 psig Capacity (scfh @ Max Del. Pressure): 9,000 Inlet Gauge Range: N/A Delivery Gauge Range: 0 - 400 psig Flow Capacity: Cv= 1.0 Ambient Operating Temperature: -40° F to +140° F Designed Leak Rate: 1 x10-8 ccs (helium) Weight: 5.8 lbs Gauge Port(s): 1/4" FNPT
Product Attributes
This series of regulators is used for applications requiring high gas flow rates and a compact design. These regulators can handle flows up to 250 liters per minute of nitrogen with only a 5 psig pressure drop. In addition, these units will handle hydrogen flow up to 1,000 liters per minute without the resonance problems associated with other regulators in this same application.
